AR905-PBB is a high-performance enterprise-level outdoor network bridge product that works in the 5G frequency band and supports 802.11ac technology. Unique digital tube matching technology.This technology requires no computer configuration and can easily complete the pairing of point-to-point and point-to-multipoint (within 8 points) devices. 100M network interface, 5G 802.11ac wireless processing speed up to 450Mbps. The power supply method is flexible and supports 24V PoE network cable power supply and 12V 1A DC local power supply. The network cable power supply distance can reach 50-70 meters (depending on the network cable material). It adopts an outdoor IP65 windproof, rainproof, dustproof, and sunproof protection grade shell design to easily adapt to various harsh outdoor environments. Built-in 14dB i high-gain, wide-angle directional plate antenna, easy and quick to install. It has the characteristics of high performance, high gain, high receiving sensitivity, high bandwidth, etc. It greatly enhances the wireless transmission performance and stability, and is widely used in medium and short distance video transmission and data transmission.
Main features:
Enterprise-level main control chip, industrial-level circuit design, supports IEEE802.11a/n/ac protocol, can provide 300Mbps wireless access speed and 10/100Mbps Ethernet switching processing speed. Excellent high and low temperature resistance design fully guarantees the real-time, long-term and stable performance of user network data in extreme environments. Transmission is reliable and efficient, improving user experience.
The circuit design of high power and high receiving sensitivity, combined with a high-gain directional plate antenna, greatly enhances the wireless transmission distance and improves wireless Transmission performance and stability.
No network expertise or computer operation is required. Simply dial the code and adjust the digital tubes of the master and slave devices to the same value to complete point-to-point and point-to-multiple. Points (within 8 points) Pairing works.
The device not only supports PoE remote network cable power supply, but also supports 12V 1A DC local connection power supply to meet various scenarios.
demand, reduce construction costs, and flexibly choose power supply methods.
The appearance is fashionable and compact, and the installation method is flexible and simple. It has wall-mounted and pole-fixed installation methods, which greatly reduces the cost without affecting the original design. Improve the construction difficulty of construction workers and improve construction efficiency.
Log in to the device with a WEB browser to view the system status, bridge status, and interface status information in real time. The simple and clear interface allows users to know in real time.Equipment working status.
Users do not need to know too much wireless knowledge or too much professional knowledge. They can achieve point-to-point and point-to-multipoint (within 8 points) devices in a few simple steps. Wireless optimization can be completed with simple settings, easily improving link transmission quality and usage effects.
The device bridge signals all adopt advanced WPA-PSK & WPA2-PSK encryption strategies. The bridge signals are hidden by default to protect the user's network from hackers at all times. attacks to ensure user data security.
| Chips | Qualcomm AR9344 |
| Main frequency | 580MHz MIPS® 24KEc™ CPU |
| wireless technology | 5G:450M 802.11a/n/ac 1T1R technology |
| Memory | 64MByte DDR2 |
| Flash | 8MB |
| Network Interface | 2*10/100Mbps adaptive RJ45 network interface (both support POE power supply) |
| power switch button | 1*Digital switch/reset button, short press the digital tube to display the value plus one, press and hold for 5 seconds to restore factory settings Master-slave DIP switch: Master is access point mode, slave is client mode |
| indicator light | Signal SIG indicator light, ETH network interface status indicator light, power indicator light, system indicator light, digital tube indicator light |
| power supply | 24V 1A non-standard PoE power supply; DC 12V 1A, power consumption 10W |
| antenna | Built-in high gain 14dB i directional plate antenna (horizontal wave half angle 60°, vertical wave half angle 15°) |
| Networking method | Point-to-point, point-to-multipoint (within 8 points) |
| network | Static IP/dynamic acquisition |
| system | Login password modification, factory reset, local upgrade |
