product description
AR718-PCB is a high-performance, high-speed indoor 11ax dual-band ceiling AP, which can provide up to 2.4G With an access rate of 574Mbps, 5G provides a maximum access rate of 1200Mbps.
Product Features
| chipset | MT7621AT+MT7905N+MT7975DN |
| Flash | SPI NOR 16MB |
| Memory | 256M |
| 2.4G frequency band | 2.4GHz–2.484GHz |
| 2.4G WIFI protocol | 802.11b/g/n/ac/ax |
| 5G frequency band | 5.150GHz-5.850GHz |
| 5G WIFI protocol | 802.11a/n/ac/ax |
| Built-in antenna 2.4G | 2 wires, high gain: 4.5DBi |
| Built-in antenna 5.8G | 2 cords, high gain: 4DBi |
| wireless speed | 2.4G 574Mbps；5.8G 1201Mbps |
| 2.4G EVM | 802.11b: -10dB; 802.11g: -25dB; 802.11n: -28dB; 802.11ax: -35dB |
| 5G EVM | 802.11a: ÿ -25 dB; 802.11n: ÿ -28 dB; 802.11ac: ÿ -32 dB; 802.11ax:-35dB |
| Frequency deviation (ppm) | ±20ppm |
| Interface (WAN) | 1*10/100/1000M adaptive WAN port, supports 48V POE power supply |
| Interface (LAN) | 1*10/100/1000M adaptive LAN port |
| POE power supply | Support 802.11af standard |
| DC powered | DC 12V 1.5A |
| button | Reset button (press and hold for 10~15 seconds to restore factory settings) |
| Status Indicator | WAN port light, LAN port light, three-color light (three different colors represent: SYS-red, 2.4G/WIFI-green color, 5.8G/WIFI-blue) |
| Maximum power | <15W |
| Product Size | 188mm*188mm*35mm |
| working environment | Working temperature: -10~55℃ Storage temperature: -40~70℃ Working humidity: 10%~90%RH non-condensing Storage humidity: 5%~95%RH non-condensing |
