PON Modem CATV 4 GE Gigabit LAN Ports AX3000 Dual Band Wifi6

Overview:

The gpon epon onu optical modem X1430-C is a XPON (GPON and EPON dual mode adaptive) optical terminal access device that is highly integrated with dual-frequency Wi-Fi6(AX3000Mbps). It is an optical fiber to the home(FTTH) terminal product of the operator. It supports ultra-bandwidth access through G/EPON upstream technology, and provides users with basic WIFI functions, routing, VOIP, gigabit Ethernet functions and client-side CATV interface functions. The X1430-C upstream network ports are G/EPON ports. The downstream user ports include four GE electrical ports, one USB port, one VOIP port, one CATV port, and one AX3000 WiFi6 WLAN port.

pon modempon modempon modem

GPon EPon ONU optical modem Interface:

  • 1 * G/EPON interface: SC/UPC/APC interface, GPON standard,EPON IEEE802.3ah
  • 4 * Ethernet interface: 10 M/100 M/1000 M RJ45, IEEE802.3-2005 standard
  • 1 * VOIP interface: in accordance with G. 711 a/u, G. 729 a/b, G. 722 standard
  • 1 * CATV, C/N:≥43dB, C/CTB:≥55dB, C/CSO≥55dB, MER≥32dB, BER≤1*10E-6
  • 1 * USB interface: standard USB 3.0 interface
  • Dual-band WIFI6 AX3000 (2 ×2 MIMO (2.4G&5G))
Hardware Parameters
Flash 256MB NAND
Memory 512MB DDR3
LED POWER+PON/LOS+NET+LAN+POTS+WiFi+CATV+WPS+USB
Port 4*RJ45(GE)
1*RJ11(POTS)
1*Reset+1*Power +1*LED button+1*WiFi button+1*WPS
1*SC/UPC (or SC/APC)
1*DC
1*USB3.0
1*CATV
Interface Parameters
G/EPON Port GPON:Class B +
EPON:PX20+
GPON:Upstream1.25Gbps;Downstream:2.48Gbps
EPON:Upstream1.25Gbps;Downstream:1.25Gbps
Ethernet Port Ethernet port-based VLAN tags and tag removal
VLAN transparent and mark
MAC address learning
100/1000/1000Mbps Autonegotiation
VoIP Port Call waiting
G711A/G711U/G729/G722
SDP protocol (RFC 2327 and RFC 4566)
T.30/T.38/G.711 fax mode
DTMF
WiFi6(AX3000)
WiFi protocol 2.4GHz supports
802.11b/g/n/ax
5GHz supports 802.11a/n/ac/ax
Transmit power 2.4G 100mW,5G /200mW,
Antenna gain 5dBi
Antenna dual-antenna MIMO (2*2) (2.4G&5G)
WLAN penetrate one reinforced concrete wall or two ordinary brick walls (non-reinforced concrete),
WLAN access capability 64 /SSID
channel 2.4GHz(channel 1-13)
5GHZ(channel 36-161 )
WPS WLAN terminal devices with WPS Push Button function establish connection within 2 minutes
WLAN security function WPA-PSK、WPA2-PSK、 WPA3、WPA-PSK/WPA2-PSK AES、AES+TKIP
Air Speed 574 Mbps (2.4GHz),2402 Mbps (5GHz)
Multicast WMM(Wi-Fi Multi Media)
CATV
Remote control CATV ON/OFF
optical AGC -10 ~ +2dBm
Output level 76dBuV
RF bandwidth 47 - 1000 MHz
In band flatness ±1.25dB
Output return loss ≥ 12dB
CATV system parameters C/N : ≥ 43dB , C/CTB : ≥ 55dB , C/CSO ≥ 55dB , MER ≥ 32dB , BER ≤1*10E-6
Environment
Operating Temperature 0℃~45℃
Storage Temperature -20℃~70℃
Operating Humidity 5%~95%(non-condensing)
Power Supply 12V/1.5A



Product Function
GPON EPON: IEEE802.3ah
GPON:ITU-T G.984.1-4G.988/TR255/TR156
15 TCONTs /256GEM ports
8 Egress queues per TCONT at least
VLAN/ priority/VEIP gem mapping mode
SN/LOID/SN+ Password authentication
Performance monitoring: eth/Gem port
Dying gasp
Layer 3 Features PPPoE/Static IP/DHCP
NAT/NAPT
Port forwarding
ALG, UPnP
DDNS
IPv6/IPv4 dual stack, and DS-Lite
Static/Default routes
Multiple services on one WAN port
RIPv2 with passive mode
Layer 2 Features MAC learning (SVL)/aging
Support max frame length to1518 bytes
VLAN tagging for untagged packets
Support VLAN 1-4094
VLAN transparent/translation
QoS Support 8 Queues with Strict Priority
Ethernet port rate limitation
802.1ppriority
SP/WRR
Service flow classification
Multicast IGMP v2 (RFC 2236) and IGMP v3 (RFC 3376)
IGMP snooping and IGMP Proxy
MLD v1/v2
Management OMCI/Web UI/TR069
Telnet/SSH management with CLI commands
Dual-system software backup and rollback
