CATV Modem Wifi Router GPon EPon ONU 4GE AC1200 USB VoIP XPon ONT Wifi5

The G1412C is a GPon and EPon dual mode adaptive optical terminal Unit that is highly integrated with dual-frequency Wi-Fi 5 AC1200. it supports ultra-bandwidth access through GEPon upstream technology and provides users with basic WiFi function, routing, and gigabit Ethernet function. The upstream network ports of the G1412C are GEPon ports. It has 4 GE RJ45 ports, 1 USB port, 1 VoIP port and WiFi 5 WLAN port. It has CATV interface to provide client TV access.

CATV Modem Wifi Router G1412C Interface :

1* G/EPON interface: SC/UPC/APC interface,
4* Ethernet interface: 10 MBPS/100 MBPS, 1000 MBPS, RJ- 45, IEEE802.3-2005 standard
1* VOlP interface: in accordance with G. 711 a/u, G. 729 a/b, G. 722 standard
1*CATV, C/N:≥43dB,C/CTB:≥55B,C/CSO>55dB, MER≥32dB, BER≤1*10E-6
1* USB interface: standard USB 2.0 interface
Dual-band WIFI5 AC1200 (2 x2 MIMO (2.4G&5G))

Hardware Parameters
PORTS:	4*RJ45(GE)
	1*RJ11(POTS)
	1Reset+1Power +1*LED
	button+1WiFi button+1WPS
	1*SC/UPC (or SC/APC)
	1*POTS
	1*DC
	1*CATV
	1*USB2.0
Size	190mm135mm33mm(LWH)
consumption	≤8W
LED	POWER+PON/LOS+NET+LAN+POTS+WiFi+WPS+USB
Interface Parameters
G/EPON Port	GPON: Class B +
	EPON: PX20+
	GPON: Upstream1.25Gbps
	Downstream: 2.48Gbps
	EPON: Upstream1.25Gbps;
	Downstream: 1.25Gbps
Ethernet Port	Ethernet port-based VLAN tags and tag removal
	VLAN transparent and mark
	MAC address learning
	10/100/1000Mbps Autonegotiation
VolP Port	Call waiting, Inconditional Call Forward
	Call Forward if Busy,Call Forward if no reply and Three-party calls.
	G711A/G711U/G729/G722
	SDP protocol (RFC 2327 and RFC 4566)
	T.30/T.38/G.711 faxmode
WiFi5
WiFi protocol	2.4GHz supports 802.11b/g/n
WiFi protocol	5GHz supports 802.11a/n/ac
Transmit power	2.4G 100mW,5G/200mW
Antenna gain	5dBi
Antenna	dual-antenna MlMO (2.4G&5G)
WLAN penetrate	one reinforced concrete wall or two ordinary brick walls (non-reinforced concrete)
WLAN access capability	64 client
channel	2.4GHz(channel 1-13), 5GHZ(channel 36-161 )
WPS	WLAN terminal devices with WPS, Push Button function establish connection within 2 minutes
WLAN security function	WPA-PSK, WPA2-PSK, WPA3, WPA-PSKNPA2-PSK, AES, AES+TKIP
Wifi rate	2.4G 300Mbps , 5G 867Mbps
CATV
Remote control CATV	ON/OFF
optical AGC	-10~+2dBm
Output level	76dBuV
RF bandwidth	47-1000 MHZ
In band flatness	+1.25dB
Qutput return loss	>12dB
CATV system parameters	C/N:> 43dB , C/CTB :≥55dB, C/CSO >55dB, MER ≥32dB, BER ≤1*10E-6
Environment
Operating Temperature	0℃~45℃
Storage Temperature	-20℃~70℃
Operating Humidity	5%~95%(non-condensing)
Power Supply	12V/1.5A
