Mini ONU 1GE Port Single Mode GPon Micro ONT Modem

Quantity:

Brand: Hosecom-PON Products

SKU:{{ product.sku }}

Model: {{ product.model }}

User Rating:

Mini ONU 1GE Port Single Mode GPon Micro ONT Modem

F601S mini ONU 1GE port HGU is a passive optical network terminal developed independently by HOSECOM. It has built-in Layer 2 switching function and Layer 3 home gateway routing function. It is a compact, high-performance and low-power consumption FTTH optical network unit.F601S mini micro ONU supports GPON operation mode and can be used in GPON network, which is very suitable for FTTH network service requirements of carriers and Internet Service Providers (ISPs).

Mini ONU 1GE port F601S Main features:

Support port - based rate limitation and bandwidth control
In compliant with lEEE802.3ah& ITU-T G.984 adaptive interface
Up to 20KM transmission distance
Support data encryption, group broadcasting, port Vlan separation ,etc.
Support Dynamic Bandwidth Allocation (DBA)
Support ONU auto-discovery/Link detection/remote upgrade of software
Support port mode of VLAN configuration
Support power - off alarm function ,easy for link problem detection
Support broadcasting storm resistance function
Support port loop detection
Support ACL to configure data packet filter flexibly
Support PPPoE/DHCP Server/IPTV/NAT
Specialized design for system breakdown prevention to maintain stable system
Support software online upgrading
Support mac/port/url filter

PON	GPON interface
	Interface Type: SC-UPC/SC-APC
	Network coverage radius:20KM
	GPoN: upstream 1.25Gbps /downstream 2.5Gbps
	Optical receive sensitivity:>-7~-28dBm
	Continuous light power:0.5dBm~+5dBm
Ethernet	1*10/100/1000M auto-negotiation
	Full/half duplex mode
	RJ45 connector
	Auto MDI/MDI-X
	100m distance
Size	105mm(L)x85mm(w)x25mm(H)
Environment	Operating temperature:0℃~60℃
	Operating humidity:10%~85% (non-condensing）
	Storage temperature:-40℃~80℃
	Storage humidity:5%~95% (non-condensing）
Power supply	12V/0.5A DC
Power supply	powerinterface size:2.1mm/5.5mm
Power	<3W
Management	Web/TELNET/TRO69/OAM/OMCI
