Router ONT 1 Port ONU G3100-CF is a residential gateway device with routing functions for XPON ONU and LAN Switch for residential and SOHO users, which is in line with ITU-T G.984 and IEEE802.3ah.

The uplink of G3100-CF provides one PON interface, while downlink provides one Ethernet and RF interface. It can realize optical access solutions such as FTTH (Fiber To The Home) and FTTB (Fiber To The Building). It fully integrates the reliability, maintainability and security design of carrier-grade equipment, and provides customers with the last kilometer of broadband access to residential and corporate customers.

Data

The Router ONT 1 Port ONU G3100-CF xPON ONT is delivered with 1GE interface, supporting:

•  Auto-negotiation and MDI/MDIX auto-sensing
•  Built-in layer-2 switch
•  Built-in layer-3 routing and residential gateway
•  Advanced data features such as VLAN tag manipulation, classification, and filtering
•  Docking compatibility with OLT of various manufacturers
•  Automatically adapt to the EPON or GPON mode used by the peer OLT

The gateway features：

•  Multiple WAN with Route/Bridge mode
•  Support multiple WAN configuration
•  Support WAN PPPoE/IPOE/Static IP/Bridge mode.
•  Automatic address assignment is supported on the LAN side
•  Network Address Translation (NAT)/Network Address Port Translation (NAPT)
•  Support Layer 2 802.1Q VLAN, 802.1P QoS,ACL etc
•  Support DDNS, ALG, DMZ, Firewall and UPNP service
•  Support NTP protocol
•  IGMP agent

Operation, management and maintenance：

•  Remote software image download, activation and restart via OAM/OMCI
•  It has two software mirror partitions, supporting software integrity checking and automatic rollback after upgrade
•  Develop TR-069 remote management function according to user requirement

CATV：

• The G3100-CF ONT supports CATV module,it can convert CATV optical signals into electrical RF signals.

Ethernet Interface：

•  10/100/1000BASE-T
•  Ethernet port auto negotiation or manual configuration
•  MDI/MDIX automatically sense
•  Virtual switch based on 802.1Q VLAN
•  VLAN tagging/detagging Ethernet port

PON Interface:

•  Compliance with IEEE 802.3ah(EPON) & ITU-T G.984.x(GPON) standard
•  BoSA on board optical solution
•  1.244 Gbps Burst Mode Upstream Transmitter
•  2.488 Gbps Downstream Receiver
•  Compliant with ITU-T G.984.2 Amd1, Class B+
•  Wavelengths: US 1310nm, DS 1490nm
•  Multiple T-CONTs per device
•  Multiple GEM Ports per device
•  Flexible mapping between GEM Ports and T-CONT
•  Activation with automatic discovered SN and password in conformance with ITU-T G.984.3
•  AES-128 Decryption with key generation and switching
•  FEC (Forward Error Correction) in both directions
•  DBA reporting by piggyback reports in the DBRu (mode 0 and mode 1)
•  Mapping of GEM Ports into a T-CONT with priority queues based scheduling
•  Support Multicast GEM port and incidental broadcast GEM port.

LED: PWR / PON / LOS / LAN / RF

Power Supply:

•  +12V/1A (feed via external AC/DC adapter)
•  2-PIN power adaptor input
•  Dying Gasp support
