ONT ONU Terminal Fiber Optical Modem Router 4 Gigabit RJ45 Ports 2.4G 5G AC1200 Dual Band Wifi

Dual Band ONT Router 4GE 4 LAN Port Fiber ONU Modem 1200Mbps Dual Band Wifi 5

G5412-A2 is a GPON EPON dual-mode adaptive XPon ONU designed by Hosecom. The upstream speed of G5412-A2 is 1.25Gbps, the downstream speed is 2.5Gbps, and the transmission distance can reach 20Km. This product provides two USB 2.0 interfaces. It adopts 4 Gigabit Ethernet ports and 1 VoIP port to provide high-performance forwarding function to ensure smooth VoIP. G5412-A2 adopts dual-band AC1200 Wifi solution, providing a maximum 1200Mbps wifi connection speed. If you are interested in this product, please contact us.

Main features:

Supports 802.11ac, Compatible with 802.11 b/g/n/ac products
Dual band – for combined wireless speeds of up to 1200Mbps at 2.4GHz and 5GHz band concurrently
Support downstream 2.5Gbps and upstream to 1.25Gbps with transmission distance to 20Km
Fiber access and gigabit port provide incredibly fast transfer speeds
Supports OMCI (ONT Management Control Interface) remote management
TDM inner transmission, support Native TDM type and CES over GEM
Pass though T-CONT-GEM port to be in progress and multiple-access BDA and QoS manage.
Easy Setup Assistant provides quick & hassle free installation

General
Equipment name	Dual band WiFi5 XPON ONU
Device mode	G5412
Type and quantity of standard user ports	4GE LAN+1POTS+1WLAN（Dual band 802.11AC）+2USB2.0
CPU Chipset	ZTE ZX279128S
WiFi Chipset	MTK MT7603EN（2.4G）
WiFi Chipset	MTK MT7613AEN（5G）
RAM	512MByte
FLASH	256MByte
Distance	20Km Max
Data Rates	Upstream:1.25Gbps, Downstream:2.5Gbps
Wireless Standards	IEEE802.11a/n/ac,5GHz 867Mbps IEEE802.11b/g/n,2.4GHz 300Mbps
Operation Frequency	2.4GHz and 5GHz
Wireless Security	WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption
VOIP Standards	SIP ITU-T G.729/G.722/G.711a/G.711
Hardware
Interfaces	1 x SC/APC XPON Port
	4 x 10/100/1000Mbps LAN Port
	1 x FXS Port
	2 x USB 2.0
Buttons	Power ON/OFF Button, WPS Button, WLAN Button, Reset Button,
Power Supply	DC 12V 1.5A
Aennant	2 x 2.4GHz/5GHz 5dBi dual-band external antennas
Dimensions (L * W * H)	205mm135mm37mm
Software Features
WAN Type	PPPoE, Static, DHCP, Bridge
VLAN Type	UnTag, Transparency, Tag
WAN Connection	Username, Password, Server Name
Quality of Service	WMM, Bandwidth Control
Port Forwarding	Virtual Server, Port Triggering, UPnP, DMZ
Application	DDNS, Advanced NAT, UPnP, Voip, IGMP, Daily Application, DMS, MLD, DNS, Samba
Firewall Security	DoS, SPI Firewall
	IP Address Filter/MAC Address Filter/Domain Filter
	IP and MAC Address Binding
VOIP Features	One RJ-11 FXS ports for connecting to analog telephones
VOIP Features	Call forwarding, Call waiting, Call block, 3-way conference call, etc.
Management	Access Control
	Local Management
	Remote Management
Internet Protocol	IPv4, IPv6
Environment
Operating Temperature	0°C~40°C (32°F~104°F)
Storage Temperature	-40°C~70°C (-40°F~158°F)
Relative Humidity	10%~90%, non-condensing
Storage Humidity	5%~95%, non-condensing
Package Contents
Package Contents	1 x XPON ONU
Package Contents	1 x Power Adapter
